Mitsubishi FX2N User Manual

Foreword
• This manual contains text, diagrams and explanations which will guide the reader in the cor-
rect installation and operation of the FX
2N
-32DP-IF Profibus-DP Interface Unit. It should be
read and understood before attempting to install or use the unit.
• Further information can be found in the FX
2N
Series and FX
0
/FX
0N
Series Hardware Man-
ual, manual of special function blocks and manual of Profibus-DP master CPUs.
• If in doubt at any stage during the installation of the FX
2N
-32DP-IF Profibus-DP Interface
Unit always consult a professional electrical engineer who is qualified and trained to the
local and national standards.
• If in doubt the operation or use of the FX
2N
-32DP-IF Profibus-DP Interface Unit please con-
sult the nearest Mitsubishi Electric distributor.
• This manual is subject to change without notice.
FX2N-32DP-IF Profibus-DP Interface Unit

Mitsubishi FX2N Specifications

General

Type	PLC
Series	FX2N
Manufacturer	Mitsubishi Electric
Power Supply	100-240VAC or 24VDC
Program Capacity	8, 000 steps
I/O Points	Up to 256 points
Expansion	Yes, via expansion modules
Instruction Set	Basic and advanced instructions
Output Type	Relay or Transistor
Humidity	5 to 95% RH, non-condensing
Communication	RS-422, RS-485
Input Points	Up to 128 points
Output Points	Up to 128 points
Execution Speed	0.08 µs per instruction
Programming Language	Instruction List
Data Memory	8, 000 words
Operating Temperature	0 to 55°C
Storage Temperature	-20°C to 70°C
