FX2N-32DP-IF Profibus-DP Interface Unit Advanced Devices 4
4-6
Note 2: Baud rate
This device shows the current baud rate of the Profibus-DP network. The baud rate depends on the
DP-master settings. The following table shows the supported baud rates and the value of D8024. If
the module is in baud search mode, this value frequently changes until the module has found a sup-
ported baud rate as follows.
Table 4.7:Baud Rate in D8024
Values in D8024
(Hex)
Baud Rate (bps)
Values in D8024
(Hex)
Baud Rate (bps)
96E2 H 9,600 05E5 H 500k
19E3 H 19.2k 15E5 H 1.5M
45E3 H 45.45k 03E6 H 3M
93E3 H 93.75k 06E6 H 6M
18E4 H 187.5k 12E6 H 12M

Mitsubishi FX2N Specifications

General

Type	PLC
Series	FX2N
Manufacturer	Mitsubishi Electric
Power Supply	100-240VAC or 24VDC
Program Capacity	8, 000 steps
I/O Points	Up to 256 points
Expansion	Yes, via expansion modules
Instruction Set	Basic and advanced instructions
Output Type	Relay or Transistor
Humidity	5 to 95% RH, non-condensing
Communication	RS-422, RS-485
Input Points	Up to 128 points
Output Points	Up to 128 points
Execution Speed	0.08 µs per instruction
Programming Language	Instruction List
Data Memory	8, 000 words
Operating Temperature	0 to 55°C
Storage Temperature	-20°C to 70°C
