3.1 Setting and change of settings
When two or more items are displayed on the screen, one of them can be selected using the following pro-
cedure. The selected item is marked with " ", and held in the memory even while the power is interrupted.
When the menu items cannot be displayed on one screen, they can be scrolled and displayed using the
cursor control keys ( ).
1. Selection of item on screen
T S
Flashing cursor is
placed at the top item .
Flashing cursor is
placed at the top item.
ENTER
Select screen
mark flashes
Cursor
is moved
T S T S
mark flashes
mark is lit.
Selection is
registered.
2. odification of set value on screen
When numeric will
be set for one item
onthe screen .
When numeric will be
set for two or more
items on the screen.
Select the desierd item using the cursor
control keys and ENTER key.
This selection procedure is not required for an
already selected item .
All values on all the screens are
chanbed by the pulsee dial .
Turn the dial clockwise to increase
the value. This setting is valid
without pressing the [ENTER] key.
Note that when any of menu 1
through menu 7 is selected, the
vallues changed will not be
protedted abainst power supply
interruption .
To protedt the set value against
power supply interruption , press
the [ENTER] key twice to register
the values in the menu table .
To change the system parameter
selection, press the [ENTER] key
once.
Set through panel
When indicated as "External" on
the screen, the setting changes
according to the external
controller setting to display on the
screen. (Setting can be made
without screen display.)
When the "External" indication
goes out , it indicates that the
external controller set value has
become smaller than the panel
set value.
Set by external trimmer
Normal setting
External analog input
Setting of items in use
• When an item which can
be modified is selected ,
under-cursor " _ " is
displayed in the numeric
input field.
• When an item which can
not be modified is
selected, the under -cursor
" _ " is not displayed.
• When any of menu 1
through menu 7 is
selected, the values will
neither be changed nor
saved unless the [ENTER]
key is pressed twice.
• See pages 70 and 71 for
the classification of the
system parameters.
The fixation of a
numeric input should
push the " ENTER "
key.
3. Operation
