Mitsubishi LE-40MTB-E - Various Setting Values

71
11.3 Various settng values
The items indicated with white letters on a black ground must be always set. Another items are set in ac-
cordance with the functinon used.
When LE-40MD reel diameter calculation unit is connected, refer to the instruction manual of the LE-40MD.
*1 : Classification in memory column
Menu refers to the data saved in the menu table memory.
System refers to the data saved as common data in the system memory.
*1 : Symbol in memory column
 : Data set on the operator screen.
c : Data set on the engineer screen displayed after the password is entered.
z : Data set on the engineer screen displayed after the password is entered or displayed for initial setting.
*2 : The initial adjustment constants are saved in the system memory.
*3 : The setting of the item marked with “
× " on the “ Setting during operation “column cannnot be changed while
the MC1 input is turned on.
Set items Set values Unit
Set range
Initial
value
Memory *1
*3
Setting
during
operation
Mainly
refer
page
Minimum Maximum Menu Syst.
Ten sion
Tension
setting
Tension set value (N) N 0.1 ,1 or 10 ~ FS tension – c18
Tension set value(×10N) N 0.01 ,0.1 or 1 ~ FS tension – c18
Full scale
tension
Full scale value – 1 1999 500 z × 12
Decimal point (N) – 0.1, 1.0 or 10 ×1 z × 12
Decimal point (×10N) – 0.01 ,0.1 or 1 ×0.1 z × 12
Tension
detector
Zero adjustment – 0 0 0
z
*2
× 12
Span adjustment
target value
N
1 digit ~ FS tension
(1/3 or more of FS tension)
500
z
*2
× 12
×10N 50.0
Filter
Display time constant s
1/4, 1/2, 1, 2,or 4
1/2 cc 35
TMO output time constant s 1/2 cc 42
Zero tension
detection
value
Zero tension (N) N 0 1999 0 c × 36
Zero tension (×10N) ×10N 0 199.9 0.0 c × 36
Manual setting Manual set value % 0 100 – c18
Taper
Linear
taper
Taper ratio(int. diameter) % 0 80 0 c31
Taper ratio(ext. diameter) % 0 100 0 c32
Non-linear
taper
Corner 1~4 mmφ 020000c33
Taper 1~4 % 0 100 0 c33
Start
Stall Stall set value % 0 100 20 c15
Timer Start timer s 0.0 10.0 4.0 cc28
Output gain
Gain 1 % 5 400 100 cc29
Gain 2 % 5 400 100 cc29
New reel
/old reel
switch-over
New reel preset value % 0 100 50 c25
Preset timer s 0.0 30.0 4.0 cc25
Old reel cut torque % 0 100 10 cc38
Stop control
Stop timer s 0.0 100.0 6.0 cc28
Stop gain % 5 400 100 cc28
Stop bias % 0 50 0 cc28
Mechanical loss
correction
Reel
A
Powder mode % 0 100 0 cc37
AC servo mode % –50 100 0 cc37
Reel
B
Powder mode % 0 100 0 cc37
AC servo mode % –50 100 0 cc37
Reel diameter
Minimum diameter mmφ 0 2000 100 z × 32
Maximum diameter mmφ
Minimum set
diameter
2000 1000 z × 32
Control gain
Manual
setting
Proportional gain (P gain) % 0 100 50 cc35
Integral time % 1 100 50 cc35
Dead zone gain % 0 100–P gain 0 cc35
Dead zone width % 0 100 50 cc35
Automatic
gain setting
Addition torque % 0 100 20 cc34
Password – 0 32767 4095 c 10
