60
Set value
No.
Set item
Variable
setting
System
setting
50
Memory switch setting 1 *
c
BIT0 Unit of tension ( N / ×10N )
BIT1 Control reel ( winding / unwinding )
BIT2 ( intremediate reel / winding reel )
BIT3 Number of reels (multiple reels / one reel )
BIT4 Taper control ( used / unused )
BIT5 Broken line taper ( broken line / straight line)
BIT 6 Taper diameter signal (external / internal )
51
Memory switch setting 2 *
c
BIT0 Actuator ( servo / powder )
BIT1 Automatic control gain ( manual / automatic )
52 AI2 setting * c
BIT0 Reel diameter
BIT1 Stall setting
BIT2 New reel preset
BIT3 Taper tatio
BIT4 Tension
53 AI3 setting * c
BIT0 Reel diameter
BIT1 Stall setting
BIT2 New reel preset
BIT3 Taper tatio
BIT4 Tension
54 MC5 setting * c
BIT0 Gain 2
BIT1 Inching
BIT2 Out remote
BIT3 Cut torque
55 MC6 setting * c
BIT0 Gain 2
BIT1 Inching
BIT2 Out remote
BIT3 Cut torque
56 Full scale tension setting c
57 Tension decimal point setting * c
BIT1 ×1 ( ×10N ) / ×10 ( N )
BIT2 ×0.1 ( ×10N ) / ×1 ( N )
BIT3 ×0.01 ( ×10N ) / × 0.1 ( N )
58 Tension display time constant setting * c
BIT0 1/4 s
BIT1 1/2 s
BIT2 1 s
BIT3 2 s
BIT4 4 s
59 Tension output time constant setting * c
BIT0 1/4 s
BIT1 1/2 s
BIT2 1 s
BIT3 2 s
BIT4 4 s
