(2) Detector type related parameters
Standard specifications
No. Abbrev. Parameter name Explanation
8
9
A
ent
B
Set the detector type.
Set the position detector type for “pen”, and the speed detector type
for “ent”. In the case of the semi-closed loop control, set the same
value for “pen” and “ent”.
C
pen
setting
ent setting Detector model name
D 0 0 OSE104
E
pen
1 1 OSA104
F 2 2 OSE105, OSA105
3 3
4 Setting impossible OHE25K-ET, OSE104-ET
5 Setting impossible OHA25K-ET, OSA104-ET
6 Setting impossible OSE105-ET, OSA105-ET
7 Setting impossible
8 Setting impossible
Relative position detection scale, MP type
(Mitsubishi Heavy Industries)
SV025 MTYP* Motor/Detector type 9 Setting impossible
AT41 (Mitsutoyo), FME type, FLE type
(Futaba)
A Setting impossible AT342 (Mitsutoyo)
B Setting impossible
C
C
(Current
synchronization)
The setting of the slave axis in the speed/current
synchronization control.
When the master axis is the semi-closed control.
D Setting impossible
E Setting impossible
F Setting impossible
Parameters with an asterisk * in the abbreviation, such as PC1*, are validated with the NC power turned ON again.
