2. Wiring and Connection

2 - 38

2-7-3 Contactor control signal (MC1) output circuit

A relay or photo coupler can be driven. Install a surge absorber (noise killer) when driving a conductive

load. (Tolerable current: 40mA or less, rush current: 100mA or less)

37kW or less

Contactor

MDS-C1-CV-370 or less

MC1

L21

L11

TE3

Triac

Surge absorber
