3-12
Instruments and controls
3
Drive mode indicator display screen
E00520800013
This displays the 4WD status.
If you select “4WD LOCK” mode with the drive
mode selector, “4WD LOCK” is displayed; if
you select “4WD AUTO” mode, “4WD” is dis-
played.
Nothing is displayed when 2WD mode is
selected. Refer to “Drive mode selector” on page
4-21.
“!” mark display screen (when the
ignition switch is “ON”)
E00520900014
This is displayed when you press the multi-infor-
mation meter switch and switch the warning dis-
play screen.
This mark is also displayed if there is another
warning other than the one displayed.
When the cause of the warning display is elimi-
nated, the “!” mark goes out automatically.
NOTE
● When the “!” mark is displayed, the warn-
ing display screen can be redisplayed on the
information screen.
Refer to “Information screen (when the
ignition switch is “OFF”)” on page 3-6.
Refer to “Information screen (when the
ignition switch is “ON”)” on page 3-13.
Active Stability Control (ASC) OFF
display screen*
E00521000012
This is displayed when the active stability con-
trol (ASC) is turned off with the ASC OFF
switch.
If there is a fault with the ASC, the ASC OFF
display is shown.
Refer to “ASC OFF switch” on page 4-37.
