Replacement of light bulbs
9-38 Vehicle care and maintenance
3. Turn the socket counterclockwise and
remove it, and then pull the bulb out of
the socket.
4. To install the bulb, perform the removal
steps in reverse.
N00929101080
1. Push the light unit upward to remove it.
2. Turn the socket (A) counterclockwise to
remove it, and then pull the bulb out of
the socket.
3. To install the bulb, perform the removal
steps in reverse.
D- Rear turn signal light
E- Tail light and stop light (LED) - cannot
be replaced
The rear side-marker light, tail light and stop
light use an LED instead of the bulb.
Check with an authorized Mitsubishi Motors
dealer or a repair facility of your choice
when the light needs to be repaired or
replaced.
When mounting the light unit, align the
notch (F) and pin (G) on the light unit with
the clip (H) and hole (I) in the body.
Back-up lights
Wrap a cloth around the tip of the screw-
driver to keep from scratching the lens.
When installing the light unit, first insert the
notch (B) into the hole on the body, and then
push on the light unit to fit it into place.
