2 - 41
2.1 System Configuration
2.1.5 Precaution on system configuration
2
SYSTEM CONFIGURATION
Remark
For restrictions on mounting the A series module on the QA6 B and
QA6ADP+A5 B/A6 B, refer to the following manual.
QA65B/QA68B Extension Base Unit User's Manual
QA6ADP QA Conversion Adapter Module User's Manual
(c) When the Redundant CPU is used
For the module having a limit to the number of mountable modules, refer to the
following manual.
QnPRHCPU User's Manual(Redundant System)
(d) When the Univarsal model QCPU is used
* 7: The CC-Link IE controller network module whose first 5 digits of serial number is "09042" or later
can only be used.
* 8: The number of mountable modules per system in the Q02UCPU is up to two in total.
* 9: The following number of modules can be controlled when the network parameter for the CC-Link
is set by GX Developer.
• Q02UCPU: Up to four modules
• Q03UDCPU, Q04UDHCPU, Q06UDHCPU, Q13UDHCPU, Q26UDHCPU, Q03UDECPU,
Q04UDEHCPU, Q06UDEHCPU, Q13UDEHCPU or Q26UDEHCPU: Up to eight modules
If the parameters are set up by CC-Link dedicated instructions, the number of modules installed
is not limited.
For the CC-Link system master/local modules whose parameters can be set up by dedicated
instructions, refer to the manual below.
CC-Link System Master/Local Module User's Manual
* 10: The number of interrupt modules where the interrupt pointer setting is not made is shown.
* 11: For applicable GOT modules, refer to the following manuals.
GOT1000 Series Connection Manual
Table2.12 Number of modules loaded
Applicable Module Type
Limitation of installable modules per
system
Q Series CC-Link IE controller
network module
*7
QJ71GP21-SX
QJ71GP21S-SX
Up to 4 in total of PLC to PLC network
and remote I/O network modules
*8
Q Series MELSECNET/H network
module
QJ71LP21
•QJ71BR11
QJ71LP21-25
QJ71LP21S-25
QJ71LP21G
QJ71LP21GE
QJ72LP25GE
Q series Ethernet interface module
QJ71E71
QJ71E71-B2
QJ71E71-B5
QJ71E71-100
Up to 4 modules
*8
Q series CC-Link system master
local module
•QJ61BT11
QJ61BT11N
No limit
*9
Interrupt module QI60
One module only
*10
GOT
GOT1000 Series
(for bus connection only)
*11
Up to 5 modules
