Mitsubishi Q01CPU User Manual

2 - 43
2.1 System Configuration
2.1.5 Precaution on system configuration
2
SYSTEM CONFIGURATION
(4) Caution for use of the High Performance model QCPU
1) When the AnS series special-function modules shown below are used, a
limitation is given to an accessible device range.
• A1SJ71J92-S3 type JEMANET interface module
• A1SD51S type intelligent communication module
2) The modules shown below cannot be used.
3) The QnA/A series dedicated instructions for the following modules are not
available.
Re-writing using the FROM/TO instruction is required.
Table2.14 Accessible device range
Device Accessible device range
Input (X), Output (Y) X/Y0 to 7FF
Internal relay (M), Latch relay (L) M0 to 8191
Link relay (B) B0 to FFF
Timer (T) T0 to 2047
Counter (C) C0 to 1023
Data register (D) D0 to 6143
Link register (W) W0 to FFF
Annunciator (F) F0 to 2047
Table2.15 Incompatible modules
Module Name Type
MELSECNET/10 network
module
A1SJ71LP21, A1SJ71BR11, A1SJ71QLP21,
A1SJ71QLP21S, A1SJ71QLP21GE, A1SJ71QBR11
MELSECNET (II), /B data link module A1SJ71AP21, A1SJ71AR21, A1SJ71AT21B
Ethernet interface module
A1SJ71QE71N-B2(-B5),
A1SJ71E71N-B2(-B5)
Serial communication module, computer link module A1SJ71QC24(N), A1SJ71UC24-R2(-PRF)
CC-Link master-local module A1SJ61QBT11, A1SJ61BT11
Modem interface module A1SJ71CMO-S3
Table2.16 Modules requiring instruction modification
Module Name Type
High speed counter module A1SD61, A1SD62, A1SD62D(-S1), A1SD62E
MELSECNET/MINI-S3 A1SJ71PT32-S3, A1SJ71T32-S3
Positioning module A1SD75P1-S3(P2-S3/P3-S3)
ID module A1SJ71ID1-R4, A1SJ71ID2-R4
