4
HARDWARE SPECIFICATIONS OF THE CPU MODULE
4.1 Performance Specifications
4.1.5 Universal model QCPU
4 - 19
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
GENERAL SPECIFICATIONS
4
HARDWARE SPECIFICATIONS OF THE CPU MODULE
5
POWER SUPPLY MODULE
6
BASE UNIT AND EXTENSION CABLE
7
MEMORY CARD AND BATTERY
8
CPU MODULE START- UP PROCEDURES
*11 : The Built-in Ethernet port QCPU is targeted.
*12 : The number indicates the total number of TCP/IP and UDP/IP protocols.
Table4.5 Performance Specifications
Item
Universal model QCPU
Q02UCPU
Q03UDCPU Q04UDHCPU Q06UDHCPU Q13UDHCPU Q26UDHCPU
Q03UDECPU Q04UDEHCPU Q06UDEHCPU Q13UDEHCPU Q26UDEHCPU
No. of device points
Interrupt pointer [I]
256 points (I0 to 255)
The constant cyclic interval of system interrupt pointers I28 to 31 can be set up by parameters.
(0.5 to 1000ms, 0.5ms unit)
Default values I28: 100ms, I29: 40ms, I30: 20ms, I31: 10ms
Special relay [SM] 2048 points (SM0 to 2047) (The number of device points is fixed.)
Special register [SD] 2048 points (SM0 to 2047) (The number of device points is fixed.)
Function input [FX] 16 points (FX0 to F) (The number of device points is fixed.)
Function output [FY] 16 points (FY0 to F) (The number of device points is fixed.)
Function register [FD] 5 points (FD0 to 4) (The number of device points is fixed.)
No. of device tracking words ----
Link direct device
Device for accessing the link device directly.
Dedicated to CC-Link IE controller network and MELSECNET/H.
Specified form: J \X , J \Y , J \W , J \B ,
J \SW , J \SB
Intelligent function module device
Device for accessing the buffer memory of the intelligent function module directly.
Specified form: U \G
Specifica
tions of
built-in
Ethernet
port
CPU
module
*11
Data transmission
speed
---- 100/10Mbps
Communication mode ---- Full-duplex/Half-duplex
Transmission method ---- Base band
Max. distance between
hub and node
---- 100m (328.08feet.)
Max.
number of
connectab
le nodes
10BASE-T ---- Cascade connection: Four stages at maximum
100BASE
-TX
---- Cascade connection: Two stages at maximum
Number of connections
*12
---- 16 for MELSOFT connection and MC protocol, 1 for FTP
