4.1 Performance Specifications
4.1.5 Universal model QCPU
4
HARDWARE SPECIFICATIONS OF THE CPU MODULE
Remark
For the general specifications, refer to CHAPTER 3.
*13 : The current consumption in the Q03UDECPU is 0.46A
*14 : The current consumption Q04UDEHCPU, Q06UDEHCPU, Q13UDEHCPU and Q26UDEHCPU is 0.46A
*15 : The values for the Built-in Ethernet port QCPU are as follows.
External dimensions (D): 115mm (4.53inch)
Weight: 0.22kg
Table4.5 Performance Specifications
Item
Universal model QCPU
Q02UCPU
Q03UDCPU Q04UDHCPU Q06UDHCPU Q13UDHCPU Q26UDHCPU
Q03UDECPU Q04UDEHCPU Q06UDEHCPU Q13UDEHCPU Q26UDEHCPU
Latch range
L0 to 8191 (8192 points by default)
(Latch range can be set up for B, F, V, T, ST, C, D, and W.) (Setting by parameters.)
RUN/PAUSE contact One contact can be set up in X0 to 1FFF for each of RUN and PAUSE. (Setting by parameters.)
Timer function
Year, month, date, hour, minute, second, and day-of-week
(leap year automatically identified)
Accuracy: -2.96 to +3.74s
(TYP.+1.42s)/d at 0
Accuracy: -3.18 to +3.74s
(TYP.+1.50s)/d at 25
Accuracy: -13.20 to +2.12s
(TYP.-3.54s)/d at 55
Allowable instantaneous power
failure period
Varies depending on the power supply module.
5VDC internal current
0.23A
0.33A
*13
0.39A
*14
External dimensions
H 98mm (3.86inch)
W 27.4mm (1.08inch)
D
89.3mm (3.52inch)
*15
Weight
0.20kg
*15
