4.3 High Performance Model QCPU, Process CPU and Redundant CPU
4.3.1 Part Names
4
HARDWARE SPECIFICATIONS OF THE CPU MODULE
*1 : When a cable is to be connected to the RS-232 connector at all times, clamp the cable to prevent a loose connection,
shifting, or disconnection by pulling due to carelessness.
The Q6HLD-R2 type RS-232 Connector Disconnection Prevention Holder is available as a clamp for RS-232
connector.
*2 : Because the DIP switches are located out of reach of fingertips, operate it with a tool such as screwdriver. Careful
attention must be paid to prevent the switch part from being damaged.
*3 : Operate the RUN/STOP switch and RESET/L.CLR switch with your fingertips.
Do not use any tool such as a screwdriver because the switch part might be damaged.
*4 : The Q12PRHCPU and Q25PRHCPU are equipped with this connector.
Diagram 4.14 RS-232 cable fixing processing
Fixing screw
Q6HLD-R2
CPU module
RS-232 cable
