5.2 Specifications
5.2.1 Power supply module specifications
5
POWER SUPPLY MODULE
*6: Although the "POWER" LED momentarily lights up in red immediately after the power supply is turned on or off, the
Q64RP is not faulty.
Table5.6 Power supply module specifications
Item
Performance Specifications
Q63RP
Base unit position Power supply module loading slot
Applicable base unit
Q3 RB, Q3 RB, Q6 WRB
Input power supply 24V DC(-35%/+30%) (15.6 to 31.2V DC)
Max. input power 65W
Inrush current 150A within 1ms
Rated output
current
5VDC 8.5A
24VDC ----
Overcurrent
protection
*1
5VDC 9.35A or more
24VDC ----
Overvoltage
protection
*2
5VDC 5.5 to 6.5V
24VDC ----
Efficiency 65% or more
Allowable momentary
power failure period
*3
Within 10ms(at 24V DC input)
Dielectric withstand
voltage
500V AC across primary and 5V DC
Insulation resistance
10M or more by insulation resistance tester
Noise durability
By noise simulator of 500Vp-p
noise voltage, 1 s noise width and 25 to 60Hz
noise frequency
Operation indication LED indication*6 (Normal operation: ON(green) Error:OFF(red)
Fuse Built-in (Unchangeable by user)
Contact output section
Application
ERR contact ( Section 5.3)
Rated switching
voltage, current
24VDC, 0.5A
Minimum
switching load
5VDC, 1mA
Response time OFF to ON: 10ms max. ON to OFF: 12ms max.
Life
Mechanical : More than 20 million times
Electrical : More than 100 thousand times at rated switching voltage, current
Surge suppressor No
Fuse No
Terminal screw size M3.5 Screw
Applicable wire size
0.75 to 2mm
2
Applicable solderless
terminal
RAV1.25-3.5, RAV2-3.5, RAV1.25-3.5, RAV2-3.5
Applicable tightening
torque
0.66 to 0.89N•m
External
dimensions
H 98mm (3.86inch)
W 83mm (3.27inch)
D 115mm (4.53inch)
Weight 0.60kg
