Mitsubishi Q01CPU User Manual

5
POWER SUPPLY MODULE
5.2 Specifications
5.2.1 Power supply module specifications
5 - 11
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
GENERAL SPECIFICATIONS
4
HARDWARE SPECIFICATIONS OF THE CPU MODULE
5
POWER SUPPLY MODULE
6
BASE UNIT AND EXTENSION CABLE
7
MEMORY CARD AND BATTERY
8
CPU MODULE START- UP PROCEDURES
*6: Although the "POWER" LED momentarily lights up in red immediately after the power supply is turned on or off, the
Q64RP is not faulty.
*7: When mounting the Q64RP to the Q65WRB, use the Q64RP whose first 6 digits of serial No. is "081103" or later.
When mounting the Q64RP whose first 6 digits of serial No. is "081102" or earlier, the vibration condition described in the
general specifications may not be met.
Table5.7 Power supply module specifications
Item
Performance Specifications
Q64RP
Base loading position Power supply module loading slot
Applicable base unit
Q3 RB, Q6 RB, Q6 WRB
*7
Input power supply
100 to 120VAC/200 to 240VAC
(85 to 132VAC/170 to 264VAC)
Input frequency
50/60Hz 5%
Input voltage
distortion factor
Within 5% ( Section 5.2.3)
Max. input apparent
power
160VA
Inrush current
20A within 8ms
*5
Rated
output
current
5VDC 8.5A
24VDC ----
Overcurrent
protection
*1
5VDC 9.35A or more
24VDC ----
Overvoltage
protection
*2
5VDC 5.5 to 6.5V
24VDC ----
Efficiency 65% or more
Allowable momentary
power failure time
*3
Within 20ms
Dielectric withstand
voltage
Across inputs/LG and outputs/FG
2830VAC rms/3 cycles (2000 m (6562 ft.))
Insulation resistance
Across inputs and outputs (LG and FG separated), across inputs and LG/FG,
across outputs and FG/LG 10M or more by insulation resistance tester
Noise durability
• By noise simulator of 1500Vp-p noise voltage, 1 s noise width and 25 to 60Hz noise frequency
• Noise voltage IEC61000-4-4, 2kV
Operation indication
LED indication (Normal: ON (green), Error: ON (red))
*6
Fuse Built-in (Unchangeable by user)
+10%
-15%
