5.2 Specifications
5.2.1 Power supply module specifications
5
POWER SUPPLY MODULE
Table5.7 Power supply module specifications
Item
Performance Specifications
Q64RP
Contact output section
Application
ERR
contact ( Section 5.3)
Rated
switching
voltage,
current
24VDC, 0.5A
Minimum
switching load
5VDC, 1mA
Response time OFF to ON: 10ms max. ON to OFF: 12ms max.
Life
Mechanical : More than 20 million times
Electrical : More than 100 thousand times at rated switching voltage, current
Surge
suppressor
No
Fuse No
Terminal screw size M3.5 screw
Applicable wire size
0.75 to 2mm
2
Applicable solderless
terminal
R1.25-3.5, R2-3.5, RAV1.25-3.5, RAV2-3.5
Applicable tightening
torque
0.66 to 0.89N•m
External
dimensions
H 98mm (3.86inch)
W 83mm (3.27inch)
D 115mm (4.53inch)
Weight 0.47kg
