6 - 4
6.1 Base Unit
6.1.1 Specification Table
6
BASE UNIT AND EXTENSION CABLE
(6) Extension base unit (Type requiring power supply module)
* 2: The 5 base mounting screws are included with the Q68B and Q612B that have 5 base mounting
holes.
(7) Redundant power extension base unit
Table6.6 Extension base unit (Type requiring power supply module) specifications
Item
Type
Q63B Q65B Q68B Q612B QA1S65B QA1S68B QA65B QA68B
Number of I/O
modules installed
358125 8 5 8
Possibility of extension Extendable
Applicable module Q series modules AnS series modules A series module
5 VDC internal current
consumption
0.11A 0.12A 0.13A 0.12A
Mounting hole size
M4 screw hole or 4.5 hole
(for M4 screw)
M5 screw hole or 5.5 hole
(for M5 screw)
External
dimensions
H 98mm (3.86inch) 130mm (5.12inch) 250mm (9.84inch)
W
189mm
(7.44inch)
245mm
(9.65inch)
328mm
(12.92inch)
439mm
(17.28inch)
315mm
(12.41inch)
420mm
(16.55inch)
352mm
(13.86inch)
466mm
(18.34inch)
D 44.1mm (1.74inch) 51.2mm (2.02inch) 46.6mm (1.83inch)
Weight 0.23kg 0.28kg 0.38kg 0.48kg 0.75kg 1.00kg 1.60kg 2.00kg
Attachment
Mounting screw M4 14 , 4 pieces *
2
(DIN rail mounting adapter sold separately)
Mounting screw M5 25
4 pieces
----
DIN rail mounting
adapter type
Q6DIN3 Q6DIN2 Q6DIN1 ---- ---- ---- ----
Table6.7 Redundant power extension base unit specifications
Item
Type
Q68RB
Number of I/O modules
installed
8
Possibility of extension Extendable
Applicable module Q series modules
5 VDC internal current
consumption
0.12A
Mounting hole size
M4 screw hole or 4.5 hole (for M4 screw)
External dimensions
H 98mm (3.86inch)
W 439mm (17.28inch)
D 44.1mm (1.74inch)
Weight 0.49kg
Attachment
Mounting screw M4 14 , 5 pieces (DIN rail mounting adapter sold separately)
DIN rail mounting adapter
type
Q6DIN1
