BASE UNIT AND EXTENSION CABLE
6.1 Base Unit
6.1.1 Specification Table
6 - 5
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
GENERAL SPECIFICATIONS
4
HARDWARE SPECIFICATIONS OF THE CPU MODULE
5
POWER SUPPLY MODULE
6
BASE UNIT AND EXTENSION CABLE
7
MEMORY CARD AND BATTERY
8
CPU MODULE START- UP PROCEDURES
(8) Redundant extension base unit
Table6.8 Redundant extension base unit specifications
Item
Type
Q65WRB
Number of I/O modules
installed
5
Possibility of extension Extendable
Applicable module Q series modules
5 VDC internal current
consumption
0.16A
Mounting hole size
M4 screw hole or 4.5 hole (for M4 screw)
External dimensions
H 98mm (3.86inch)
W 439mm (17.28inch)
D 44.1mm (1.74inch)
Weight 0.52kg
Attachment
Mounting screw M4 14 , 5 pieces (DIN rail mounting adapter sold separately)
DIN rail mounting adapter
type
Q6DIN1
