9.1 Requirements for Conformance to EMC Directive
9.1.5 When Using MELSEC-A Series Modules
9
EMC AND LOW VOLTAGE DIRECTIVES
(2) Power supply module
The precautions required for each power supply module are described in Table9.4.
Always observe the items noted as precautions.
* 1: If sufficient filter circuitry is built into the 24VDC external power supply module, the noise
generated by A1S63P will be absorbed by that filter circuit, so a line filter may not be required.
Filtering circuitry of version F or later of A1S63P is improved so that a external line filter is not
required.
Table9.4 Precautions when using a power supply module
Model Precautions
A1S61P
A1S62P
A61P
A62P
Not usable
A1S63P
*1
A163P
Use the CE marked 24VDC panel power equipment.
A1S61PEU
A1S62PEU
A1S61PN
A1S62PN
A61PN
A61PEU
A62PEU
A68P
Always ground the LG and FG terminals after short-
circuiting them.
