TROUBLESHOOTING
12.2 Troubleshooting
12.2.2 Flowchart for when the ERR terminal (negative logic) is turned off (opened)
12 - 7
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
Errors that can be detected by the ERR terminal
The following shows the errors that can be detected by the ERR terminal of the power
supply module in a singular power supply system/redundant power supply system.
<Singular power supply system> ................ One Q series power supply module is
used.
* : Except the Q00JCPU (without ERR terminal).
<Singular power supply system> ................ One slim type power supply module is
used.
* : Except the Q00JCPU (without ERR terminal).
<Redundant power supply system> ................. Two redundane power supply modules
are used.
* : Except the Q00JCPU (without ERR terminal).
Table12.1 Errors that can be detected by the ERR terminal of a power supply module
Base unit
CPU module
Basic model QCPU*,
High Performance model QCPU, Process CPU,
Universal model QCPU
Redundant CPU
Main base unit (Q3 B)
AC power not input, power supply module fuse blown and CPU module stop error
(including reset) can be detected.
Multiple CPU high speed main
base unit (Q3 DB)
Extension base unit (Q6 B)
Errors cannot be detected (always OFF). (Cannot be added)
Table12.2 Errors that can be detected by the ERR terminal of a power supply module
Base unit
CPU module
Basic model QCPU*,
High Performance model QCPU,
Universal model QCPU
Process CPU,
Redundant CPU
Slim type main base unit
(Q3 SB)
AC power not input, power supply module fuse blown
and CPU module stop error (including reset) can be
detected.
(Cannot be combined)
Table12.3 Errors that can be detected by the ERR terminal of a power supply module
Base unit
CPU module
Basic model QCPU*,
High Performance model QCPU, Process CPU,
Universal model QCPU
Redundant CPU
Redundant power main base unit
(Q3 RB)
AC power not input, redundant power supply module fuse blown, CPU module stop
error (including reset), and redundant power supply module failure can be detected.
Redundant power extension base
unit (Q6 RB)
AC power not input, redundant power supply module
fuse blown, and redundant power supply module failure
can be detected.
(Cannot be added)
