12.2 Troubleshooting
12.2.24 Flowchart for when PARAMETER ERROR occurs at power ON/reset.
12 - 33
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
(4) Flowchart for when PARAMETER ERROR (error code: 3042) occurrs.
NO
YES
NO
Is the parameter-valid
drive set in the program
memory?
The PARAMETER ERROR
(error code: 3042) has occurred.
Is the "PARAM" set for
booting to the program
memory with the "Boot
file setting" of the PLC
parameter?
YES
Set the "PARAM" for booting to the
program memory with the "Boot file
setting" of the PLC parameter.
Write the "parameter
(PLC/Network/Remote)" to the
parameter-valid drive on GX
Developer.
Switch the power of the system from
OFF to ON or reset the CPU
module.
NO
YES
YES
Since the CPU module may be
faulty, please contact your local
Mitsubishi representative, explaining
a detailed description of the problem.
Is the PARAMETER ERROR
(error code: 3042) detected
again?
Has the "Target
memory" selected the
current parameter-valid
drive on the screen of
write to PLC of GX
Developer?
Select a parameter-valid drive with
the "target memory" on the PLC
writing screen of GX Developer.
Completed
