TROUBLESHOOTING
12.3 Error Code List
12.3.11 Error codes returned to request source during communication with CPU module
12 - 227
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
Table12.12 Error code
Error code
(Hexadecimal)
Error item Error details Corrective action
408A
H
Other errors
The file capacity was exceeded by the write
during Run.
• Check the capacity of the specified program file.
• Write the program after setting the CPU module to the
STOP status.
408B
H
The remote request cannot be executed.
• Reexecute after the CPU module is in a status where
the mode request can be executed.
• For remote operation, set the parameter to "Enable
remote reset".
408C
H
An attempt was made to remote-start the
program, which uses the CHK instruction, as a
low speed program.
• The program including the CHK instruction cannot be
executed at low speed. Execute again after checking
the program.
408D
H
The instruction code that cannot be handled
exists.
• Check whether the model of the used CPU module is
correct or not.
• The sequence program where online program change
was attempted includes the instruction that cannot be
handled by the CPU module model name set in the
project. Reexamine the sequence program and delete
that instruction.
408E
H
The write step is illegal.
• Write the program after setting the CPU module to the
STOP status.
• The starting position of online program change is not
specified with the correct program step No. Check
whether the used peripheral device supports the CPU
module model name and CPU module version set in
the project.
40A0
H
SFC device
specification
error
A block No. outside the range was specified. Check the setting contents and make a correction.
40A1
H
A number of blocks that exceeds the range
was specified.
Check the number of settings and make a correction.
40A2
H
A step No. that is outside the range was
specified.
Check the setting contents and make a correction.
40A3
H
Step range limit exceeded Check the number of settings and make a correction.
40A4
H
The specified sequence step No. is outside
the range.
Check the setting contents and make a correction.
40A5
H
The specified device is outside the range. Check the number of settings and make a correction.
40A6
H
The block specification pattern and step
specification pattern were wrong.
Check the setting contents and make a correction.
40B0
H
SFC file
related error
The drive (memory) specified in SFC file
operation is wrong.
Check the setting contents and make a correction.
40B1
H
The SFC program specified in SFC file
operation does not exist.
Check the specified file name and make a correction.
40B2
H
The program specified in SFC file operation is
not an SFC program.
Check the specified file name and make a correction.
40B3
H
Using online program change of SFC, an
attempt was made to execute rewrite
operation of the "SFC dedicated instruction",
such as the "STEP start instruction or
transition start instruction", that shows an SFC
chart.
(SFC dedicated instruction cannot be written
during RUN.)
Write the program after setting the CPU module to the
STOP status.
