Mitsubishi Q01CPU User Manual

12 - 228
12.3 Error Code List
12.3.11 Error codes returned to request source during communication with CPU module
12
TROUBLESHOOTING
Table12.12 Error code
Error code
(Hexadecimal)
Error item Error details Corrective action
4100
H
Other errors
CPU module hardware fault Change the CPU module.
4101
H
Serial communication connection was
executed for a different CPU module series.
Check the CPU module series.
4102
H
An attempt was made to erase the Flash ROM
during use of the file register.
Execute again after setting the CPU module to the STOP
status.
4103
H
The instruction written during RUN is wrong or
illegal.
Execute online program change again, or write the
program after setting the CPU module to the STOP
status.
4105
H
CPU module internal memory hardware fault Change the CPU module.
4106
H
The command cannot be executed since the
CPU module is performing system initialization
processing.
Execute the operation again after the CPU module has
started.
4107
H
An attempt was made to perform the operation
of the function unavailable for the target CPU
module model name.
Do not execute the function unsupported by the target
CPU module.
4108
H
Operation cannot be made normally by device
monitor/test.
Execute device monitor/test again. Before execution,
check that access is not made to the access prohibited
area.
4109
H
The specified operation cannot be executed
since the monitoring, set the condition for
other application in same computer, is in
execution.
Execute the request again after deregistering the
monitoring condition on the same screen.
410A
H
The specified command cannot be executed
because of online prgram change.
Execute the request again after the online program
change.
410B
H
The registration of monitoring condition was
canceled because of online program change.
Execute the registration of monitoring condition again
after the online program change.
4110
H
CPU mode
error
Since the CPU module is in a stop error
status, it cannot execute the request.
Execute the request again after resetting the CPU
module.
4111
H
The requested operation cannot be performed
since the other CPU modules have not yet
started in the multiple CPU system.
Execute the request again after the other CPU modules
have started.
