1
OVERVIEW
1.1 Features
1 - 14
1
OVERVIEW
2
SYSTEM
CONFIGURATION
3
GENERAL
SPECIFICATIONS
4
HARDWARE
SPECIFICATIONS OF
THE CPU MODULE
5
POWER SUPPLY
MODULE
6
BASE UNIT AND
EXTENSION CABLE
7
MEMORY CARD AND
BATTERY
8
CPU MODULE START-
UP PROCEDURES
(3) Realised high speed processing
High speed processing has been achieved.
The MELSEC Q series base unit high-speed system bus has achieved faster access
to an intelligent function module and link refresh with a network module.
(a) Basic model QCPU
MELSECNET/H link refreshing: 2.2ms/2k words
*1
*1: This is the case that the Q01CPU is used without using SB/SW and the
MELSECNET/H network module is installed to the main base unit.
(b) High Performance model QCPU, Process CPU, Redundant CPU or
Universal model QCPU
Access to the intelligent function module: 20 s/word (approximately 7 times
*2
)
MELSECNET/H link refreshing: 4.6ms/8k words (approximately 4.3 times
*2
)
*2: These are the values resulted from the following comparison:
•Comparing Q02HCPU with Q2ASHCPU-S1
•Comparing Q25PHCPU with Q4ARCPU
•Comparing Q25PRHCPU with Q4ARCPU
Table1.12 Processing speed (LD instruction)
CPU module type
LD instruction processing
speed
Basic model QCPU
Q00JCPU 200ns
Q00CPU 160ns
Q01CPU 100ns
High Performance model QCPU
Q02CPU 79ns
Q02HCPU, Q06HCPU,
Q12HCPU, Q25HCPU
34ns
Process CPU Q12PHCPU, Q25PHCPU
Redundant CPU Q12PRHCPU, Q25PRHCPU
Universal model QCPU
Q02UCPU 40ns
Q03UDCPU 20ns
Q04UDHCPU, Q06UDHCPU,
Q13UDHCPU, Q26UDHCPU
9.5ns
