App - 12
Appendix 1 External Dimensions
Appendix 1.3 Main base unit
APPENDICES
(b) Q312B with 4 base mounting holes
(5) Q32SB
(6) Q33SB
Unit : mm (inch)
Diagram App.19 Q312B (4 base mounting holes)
Unit : mm (inch)
Diagram App.20 Q32SB
Unit : mm (inch)
Diagram App.21 Q33SB
7.5
(0.30)
44.1
(1.74)
(0.61)
15.5
98 (3.86)
7
(0.28)
439 (17.28)
4-mounting screws (M4×14)
80 0.3
(3.15 0.01)
419 0.3 (16.50 0.01)
OUT
7.5
18.5
(0.30)
(0.73)
SG
5V
I/O0
I/O1
CPU
POWER
114 (4.49)
98 (3.86)
7
(0.28)
80 0.3
(3.15 0.01)
8.5 (0.33)
101 0.3 (3.98 0.01)
4-mounting screws (M4×12)
7.5
(0.30)
18.5
(0.73)
142 (5.59)
98 (3.86)
7
(0.28)
80 0.3
(3.15 0.01)
8.5 (0.33)
129 0.3 (5.08 0.01)
SG
5V
I/O2I/O0 I/O1CPU
POWER
4-mounting screws (M4×12)
