Mitsubishi Q01CPU

APPENDICES
Appendix 1 External Dimensions
Appendix 1.3 Main base unit
App - 13
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTINGAPPENDICES INDEX
(7) Q35SB
(8) Q38RB
Unit : mm (inch)
Diagram App.22 Q35SB
Unit : mm (inch)
Diagram App.23 Q38RB
7.5
(0.30)
18.5
(0.73)
197.5 (7.78)
98 (3.86)
7
(0.28)
80 0.3
(3.15 0.01)
8.5
(0.33)
184.5 0.3 (7.26 0.01)
4-mounting screws (M4×12)
SG
5V
OUT
439 (17.28)
I/O7I/O6I/O5I/O4I/O3
5V
FG
SG
I/O2I/O1I/O0
5V
FG
CPU
SG
(M4×14)
7.5
(0.30)
44.1 (1.74)
98 (3.86)
7
(0.28)
15.5 (0.61)
80 0.3
170 0.3 (6.69 0.01) 249 0.3 (9.80 0.01)
5-mounting
screws
(3.15 0.01)
