Mitsubishi Q01CPU

App - 20
Appendix 1 External Dimensions
Appendix 1.4 Extension base unit
APPENDICES
(11) Q68RB
(12) Q65WRB
Unit : mm (inch)
Diagram App.38 Q68RB
Unit : mm (inch)
Diagram App.39 Q65WRB
FG
SG
5V
5V
SG
FG
I/O0 I/O1 I/O2 I/O3 I/O4 I/O5 I/O6 I/O7
OUTIN
439 (17.28)
7.5
(0.30)
15.5
(0.61)
44.1 (1.74)
98 (3.86)
7
(0.28)
80 0.3
170 0.3 (6.69 0.01) 247 0.3 (9.72 0.01)
5-mounting
screws
(3.15 0.01)
(M4×14)
POWER 2
SG
5V
5V
SG
POWER 1
I/O0 I/O1 I/O2 I/O3 I/O4
IN2 OUTIN1
439 (17.28)
7.5
(0.30)
15.5
(0.61)
44.1
(1.74)
98 (3.86)
7
(0.28)
80 0.3
170 0.3 (6.69 0.01) 247 0.3 (9.72 0.01)
5-mounting
screws
(3.15 0.01)
(M4×14)
