APPENDICES
Appendix 1 External Di
mensions
Appendix 1.4 Extension base unit
App
- 19
9
EMC AND LOW
VOL
TA
GE
DIRECTI
VES
10
LOADING AND
INST
ALLA
TION
11
MAINTENANCE AND
INSPECTION
12
TROUBLESHOOTING
APPENDICES
INDEX
(9)
QA65B
(10) QA68B
Unit : mm (inch)
Diagram App.36 QA65B
Unit : mm (inch)
Diagram App.37 QA68B
Base cover
2 6-M4 screw
(for module installation)
4- 6 installation holes
(M5 mounting screw)
Hand hold
200 0.3
250 (9.84)
46.6
(1.83)
332 0.3 (13.07 0.01)
352 (13.87)
(7.87 0.01)
Base cover
2 9-M4 screw
(for module installation)
4- 6 installation holes
(M5 mounting screw)
Hand hold
250 (9.84)
200 0.3
(7.87 0.01)
46.6
(1.83)
446 0.3 (17.56 0.01)
466 (18.35)
704
706
