Mitsubishi Q01CPU User Manual

App - 18
Appendix 1 External Dimensions
Appendix 1.4 Extension base unit
APPENDICES
(7) QA1S65B
(8) QA1S68B
Unit : mm (inch)
Diagram App.34 QA1S65B
Unit : mm (inch)
Diagram App.35 QA1S68B
51.2
(2.02)
315 (12.40)
130 (5.12)
IN OUT
16.4
(0.65)
10
(0.39)
POWER
5V
SG
FG
I/O0 I/O1 I/O2 I/O3 I/O4
QA1S65B
4-mounting screws (M5×25)
110 0.3 (4.33 0.01)
295 0.3 (11.61 0.01)
10
(0.39)
I/O0 I/O7I/O6I/O5I/O4I/O3I/O2I/O1
QA1S68B
16.4
51.2
10
(0.39)
420 (16.54)
130 (5.12)
10
(0.39)
IN OUT
POWER
5V
SG
FG
110 0.3 (4.33 0.01)
400 0.3 (15.75 0.01)
4-mounting screws (M5×25)
(2.02)
(0.65)
