6 - 19
6 INSPECTION AND MAINTENANCE
(c) Flowchart for when "A00" displays on 7-segment LED
"A00" displays when the operating system software is not installed.
The following shows the flowchart for when "A00" displays on 7-segment
LED at the power supply ON or operation start.
END
YES
NO
YES
NO
Explain the error symptom and get
advice from our sales representative.
"A00" displays on 7-segment LED
Is the
operating system
software installed to Motion
controller?
Install the operating system software.
Reset the Motion controller.
Does "A00" disappear
on 7-segment LED?
To Next Page
