Mitsubishi Q170MCPU User Manual

APP - 51
A
PPENDICES
APPENDIX 5.4 Battery holder
(1) Battery holder (For Q6BAT)
[Unit: mm (inch)]
PUSH
47.2(1.86) 1.5(0.06)2.4(0.09)
25.35(1.00)
27.15(1.07)
19.9(0.78)
49.6(1.95) 22.6(0.89)
23.9(0.94)
26.2(1.03)
3.1(0.12)
6.9(0.27)
(2) Battery holder (For Q7BAT)
[Unit: mm (inch)]
PUSH
10
29.4(1.16)
29.4(1.16)
47.2(1.86)
18(0.71) 45.9(1.81)
26.2(1.03)
27.7(1.09)
34.7(1.37)
27.4(1.08)
2.4(0.09)
1.5(0.06)
6.9(0.27)
2(0.08)
4.8(0.19)
(0.39)
