2 - 47
2 SYSTEM CONFIGURATION
2.5.5 Manual pulse generator
(1) Manual pulse generator specifications
Item Specifications
Model name MR-HDP01
(Note-1)
Ambient temperature -10 to 60°C(14 to 140°F)
Pulse resolution 25PLS/rev(100 PLS/rev after magnification by 4)
Output method Voltage-output/Output current : Up to 20mA
Power supply voltage 4.5 to 13.2VDC
(Note-2)
Current consumption [mA] 60
Life time 1,000,000 revolutions or more (at 200r/min)
Permitted axial loads Radial load : Up to 19.6N, Thrust load : Up to 9.8N
Mass [kg] 0.4
Number of max. revolution Instantaneous Up to 600r/min. normal 200r/min
Pulse signal status
2 signals : A phase, B : phase, 90° phase difference
Start friction torque 0.06N•m (20°C (68°F) )
(Note-1) : Use MR-HDP01 by connecting with Q173DPX.
(Note-2) : If a separate power supply is used, use a stabilized power supply of voltage 5VDC ±
0.25V.
