Mitsubishi Q170MCPU User Manual

APP - 52
A
PPENDICES
APPENDIX 5.5 Connector
(1) SSCNET cable connector
[Unit: mm (inch)]
20.9 0.2
(0.82 0.01)
17.6 0.2
(0.69 0.01)
8
(0.31)
2.3
(0.09)
1.7
(0.07)
4.8(0.19)
13.4
(0.53)
15
(0.59)
6.7
(0.26)
9.3(0.37)
(2) Forced stop input connector (Molex Incorporated make)
Type Connector : 5557-02R-210
Terminal : 5556PBTL
[Unit: mm (inch)]
10.6
10.7
19.6 (0.77)
8.56.3
3.5
(0.14)
(0.42)
(0.42)
(0.33)(0.25)
9.6
(0.38)
5.4
(0.21)
