2 SYSTEM CONFIGURATION
2.5.8 Forced stop input terminal
(1) Table of the forced stop input terminal specifications
Item Specifications
Number of input points Forced stop signal : 1 point
Input method Sink/Source type
Rated input current 2.4mA
Isolation method Photocoupler
Operating voltage range
20.4 to 26.4VDC
(+10/ -15%, ripple ratio 5% or less)
ON voltage/current 17.5VDC or more/2.0mA or more
OFF voltage/current 1.8VDC or less/0.18mA or less
Input resistance Approx. 10k
OFF to ON
Response time
ON to OFF
1ms or less
External connector type 2 pin connector
Applicable wire size
0.3mm
2
(AWG22)
