Mitsubishi Q170MCPU - APPENDIX 4.2 Forced Stop Input Cable

APP - 47
A
PPENDICES
APPENDIX 4.2 Forced stop input cable
Generally use the forced stop input cable available as our products. If the required
length is not found in our products, fabricate the cable on the customer side. Make the
forced stop input cable within 30m(98.43ft.).
(1) Q170DEMICBL M
(a) Model explanation
Type : Q170DEMICBL M
1
Cable length [m(ft.)]
5
Symbol
10
1(3.28)
3(9.84)
5(16.40)
3
10(32.81)
15 15(49.21)
20
25
20(65.62)
25(82.02)
30
30(98.43)
05
0.5(1.64)
(b) Connection diagram
(
Note
)
: Use a cable of wire size AWG24.
2
1
EMI.COM
EMI
EMI.COM
EMI
2
1
Solderless terminal
5556PBTL (Terminal)
5557-02R-210 (Connector)
: Twisted pair cable
Solderless terminal size: R1.25-3.5
Q170MCPU side
