APP - 46
PPENDICES
• MR-J3BUS03M to MR-J3BUS3M
Refer to the table of this section (1) for cable length (L).
[Unit: mm(inch)]
L
(Note)
100
(3.94)
100
(3.94)
Protective tube
(Note) : Dimension of connector part is the same as that of MR-J3BUS015M.
• MR-J3BUS5M-A to MR-J3BUS20M-A,MR-J3BUS30M-B to
MR-J3BUS50M-B
Refer to the table of this section (1) for cable length (L).
Variation [mm(inch)]
SSCNET cable
A B
MR-J3BUS5M-A to MR-J3BUS20M-A 100(3.94) 30(1.18)
MR-J3BUS30M-B to MR-J3BUS50M-B 150(5.91) 50(1.97)
[Unit: mm(inch)]
(A)
(A)
L
(B)(B)
(Note)
Protective tube
(Note) : Dimension of connector part is the same as that of MR-J3BUS015M.
POINTS
Keep the cap and the tube for protecting light cord end of SSCNET cable in a
plastic bag with a zipper of SSCNET
cable to prevent them from becoming dirty.
