POINTS
(1) If the end face of cord tip for the SSCNET cable is dirty, optical transmission
is interrupted and it may cause malfunctions. If it becomes dirty, wipe with a
bonded textile, etc. Do not use solvent such as alcohol.
(2) Do not add impossible power to the connector of the SSCNET
cable.
(3) When incinerating the SSCNET
cable (optical fiber), hydrogen fluoride gas or
hydrogen chloride gas which is corrosive and harmful may be generated. For
disposal of the SSCNET
cable (optical fiber), request for specialized
industrial waste disposal services who has incineration facility for disposing
hydrogen fluoride gas or hydrogen chloride gas.
(a) MR-J3BUS M
1) Model explanation
015
Cable length [m(ft.)]
05
1
0.15(0.49)
0.3(0.98)
0.5(1.64)
03
1(3.28)
A
Symbol
B
Cable type
Standard cord for inside panel
Standard cable for outside panel
Long distance cable
33(9.84)
5
10
20
30
40
50
Symbol
Type: MR-J3BUS M-
None
5(16.40)
10(32.81)
20(65.62)
30(98.43)
40(131.23)
50(164.04)
2) Exterior dimensions
• MR-J3BUS015M
[Unit: mm(inch)]
2.3(0.09)
1.7(0.07)
37.65
(1.48)
150
+50
- 0
(5.91)
8
+0
(0.31)
20.9(0.82)
13.4
(0.53)
6.7(0.26)
15
(0.59)
Protective tube
