Mitsubishi Q170MCPU - APPENDIX 5.2 Servo External Signals Interface Module (Q172 DLX); APPENDIX 5.3 Manual Pulse Generator Interface Module (Q173 DPX)

APP - 50
A
PPENDICES
APPENDIX 5.2 Servo external signals interface module (Q172DLX)
[Unit: mm (inch)]
Q172DLX
Q172DLX
CTRL
90(3.54)
98(3.86)
45(1.77)
4(0.16)
23(0.91)
27.4(1.08)
APPENDIX 5.3 Manual pulse generator interface module (Q173DPX)
[Unit: mm (inch)]
Q173DPX
Q173DPX
1
2
3
PLS.A
1
2
3
PLS.B
1
2
3
TREN
PULSER
61 2345
ON
90(3.54)
98(3.86)
45(1.77)
4(0.16)
23(0.91)
27.4(1.08)
