Mitsubishi Q170MCPU User Manual

APP - 13
A
PPENDICES
3) Precautions
Precautions for connection between the Motion controller and
MT Developer2 via HUB are shown below.
a) When the personal computer that can connect to LAN line is used,
set the same value for Motion controller IP address as the following
personal computer IP address.
192 168 3 39
Motion controller
IP address
Set the same value as the
personal computer IP address
(Example) Personal computer IP address: "192.168.3.1"
<Setting for Motion controller side>
Set the same value as the personal
computer IP address.
(Example) 192.168.3.
Set the IP address not used with devices
connected to network.
(Example) . . .39
Set the same value as the Motion
controller IP address.
(Example) 192.168.3.39
<Setting for MT Developer2 side>
