Mitsubishi Q170MCPU User Manual

APP - 26
A
PPENDICES
2) SV22 (Q170M_SV22_MT2)
a) Base setting
Setting items Description
Stage 1 Nothing
Extension base
Stage 2 Nothing
b) Multiple CPU setting
Setting items Description
Operating mode All station stop by stop error of CPU 1/2
Multiple CPU synchronous startup setting Set CPU No. 1/2 to synchronous startup
c) Multiple CPU high speed transmission area setting
CPU specific send range
User setting area Automatic refresh
CPU
Points (k)
Points Start End Points
No.1 7 6980 G10000 G16979 188
No.2 7 5840 G10000 G15839 1328
d) Automatic refresh setting
• CPU No.1 (Receive)
Automatic refresh CPU specific send range(U3E0\)
Setting No.
Points Start End Start End
1 28 M3072 M3519
G16980 G17007
2 42 M4800 M5471
G17008 G17049
3 118 D640 D757
G17050 G17167
• CPU No.2 (Send)
Automatic refresh CPU specific send range(U3E1\)
Setting No.
Points Start End Start End
1 46 M2000 M2735
G15840 G15885
2 42 M4000 M4671
G15886 G15927
3 320 D0 D319
G15928 G16247
4 600 D800 D1399
G16248 G16847
5 320 #8000 #8319
G16848 G17167
