2 - 2
2 SYSTEM CONFIGURATION
(2) Peripheral device configuration for the Q170MCPU
The following (a)(b)(c) can be used.
Personal computer
Motion controller
(Q170MCPU)
(a) USB configuration (b) RS-232 configuration (c) Ethernet configuration
Motion controller
(Q170MCPU)
Motion controller
(Q170MCPU)
Personal computer Personal computer
RS-232 communication cable
(QC30R2)
Ethernet cable
USB cable
