2 - 9
2 SYSTEM CONFIGURATION
(2) Motion module (Q172DLX/Q173DPX)
(a) Rating plate
The rating plate is situated on the side face of the Motion module.
(b) Front of Motion module
The serial No. is printed in the projection parts forward of the lower side of
Motion module.
MODEL
PASSED
Q172DLX
Q172DLX
CTRL
MITSUBISHI
US L ISTED
U
L
80M1 IND. CONT. EQ.
C
CLASS 2 ONL Y
Rating plate
Serial numbe
Serial number
B86054999
MOTION I/F UNIT
SERIAL
B86054999
MITSUBISHI ELECTRIC
JAPAN
Q172DLX
12/24VDC 2/4mA
REMARK
The serial number display was corresponded from the Motion modules
manufactured in early April 2008.
