3 - 15
3 DESIGN
(h) Power consumption of the external power supply section of the intelligent
function module.
W
S = 0.12 24 = 2.88 [W]
(i) Power consumption of overall system
W = 17.975 + 4.494 + 38.4 + 0.32 + 1.536 + 2.88 = 65.605 [W]
