9 - 7 9 - 7
MELSEC-Q
9 PARAMETER LIST
Default Value Setting Range Reference Section
———
No setting
• PLC CPU No.2 to No.4: PLC No.n/Empty (Designate "CPU
(empty)" for slots where no CPU module is installed.)
•
Input/output module and intelligent function module
• Input, high speed input, output, intelligent, input/output
mixture, interrupt
No setting
•
16 single-byte characters
No setting
•
0 point, 16 points, 32 points, 48 points, 64 points, 128
points, 256 points, 512 points, 1024 points
No setting • 0H to FF0H
Section 5.6
No setting
•
16 single-byte characters
No setting
•
16 single-byte characters
No setting
•
16 single-byte characters
No setting
•
2,3,5,8,10,12
Section 5.3
No setting
• See the manual of the intelligent function module to
be used.
Section 7.6
Clear • Cleared/retained
Stop
•
Stopped/continue
—
Input, I/O mixture: 10 ms
High speed input: 0.2 ms
•
Input, I/O mixture: 1 ms, 5 ms, 10 ms, 20 ms,
70 ms
•
High speed input: 0.1 ms, 0.2 ms, 0.4 ms, 0.6 ms, 1.0 ms
Section 7.7
PLC No.1
•
PLC
No.1, PLC No.2, PLC No.3, No.4 Section 14.2.1
—
——
———
1 module • 1 to 4 modules Section 14.2.1
Stop all PLCs upon error of PLC No.n • Stop or do not stop all PLCs upon an error of PLC No.n. Section 14.2.8
Do not permit inputs from outside
group
•
Permit or do not permit inputs from outside the group. Section 17.2
Do not permit outputs to outside group
•
Permit or do not permit outputs to outside the group. Section 17.2
•
Setting range of each CPU: 0 to 2048 points (in 2-point
intervals) / module
Max. 4k points (4096 points) /
system
No setting
•
Device on CPU side: B, M, Y, D, R, ZR
Devices equivalent to the number of
points set for the transmission range
from the designated device number
are occupied.
•
16 points are occupied with B, M and
Y for each point of transmission
range.
•
1 point is occupied with D, W, R and
ZR for each point of transmission
range.
Section 16.1
To Next Page
