9 - 46 9 - 46
MELSEC-Q
9 UTILITY PACKAGE (GX Configurator-SC)
[Monitor/Test items]
Buffer memory address
Item
CH1 CH2
Reference section
Data transmission result 257H 267H
Data reception result 258H 268H
Chapter 11
Receive user frame nth 25BH 26BH
User frame being transmitted B6H 156H
User's Manual (Application)
X00: CH1 Transmission normal completion/
X07: CH2 Transmission normal completion
X01: CH1 Transmission abnormal completion/
X08: CH2 Transmission abnormal completion
X02: CH1 Transmission processing in progress/
X09: CH2 Transmission processing in progress
X03: CH1 Reception data read request/
X0A: CH2 Reception data read request
X04: CH1 Reception abnormal detection/
X0B: CH2 Reception abnormal detection
Y00: CH1 Transmission request/
Y07: CH2 Transmission request
Y01: CH1 Reception data read completion/
Y08: CH2 Reception data read completion
— —
Received data count designation A4H 144H
Receive complete code designation A5H 145H
Chapter 6
User frame use enable/disable designation ADH 14DH
First frame No. designation 1st to 4th AEH to B1H
14E
H to
151H
Last frame No. designation 1st to 4th B2H to B5H
152H to
155
H
User frame receive format designation 1st to
4th
2020H to
2023H
2120H to
2123H
Receive user
frame
designation
Exclusive format-1 received data count 1st to
4th
2024H to
2027H
2124H to
2127H
CR/LF output designation B7H 157H
Output head pointer designation B8H 158H
Transmission
user frame
designation
Output count designation B9
H 159H
User's Manual (Application)
Timeout at No-protocol 2014H 2114H User's Manual (Application)
Receive data clear request A8H 148H Chapter 6
