App. - 48 App. - 48
MELSEC-Q
A
PPENDIXES
Appendix 9.7 When sending data using user frames
The following program example sends data by the user frames using the
REMFR/REMTO instruction and I/O signals.
Refer to the User's Manual (Application) for the transmission using the user frames.
(1) Program conditions
The following program sends data using the user frames from the CH1 side when
the transmission signal (X1026) turns ON.
(a) Devices used
:
• Transmission command ......................................................... X1026
• Transmission command pulse signal ..................................... M10
• Transmission user frame designation command................... M11
• Transmission result acquisition command ............................. M12
• Completion device for REMFR/REMTO instruction ............... M100 to 105
• Normal/abnormal completion flag for REMFR/REMTO
instruction................................................................................ M200 to 203
• Normal/abnormal completion of transmission........................ M300, M301
• Transmission data count......................................................... D0
• Transmission data................................................................... D1, D2
• CR/LF output designation ....................................................... D5
• Output head pointer designation............................................. D6
• Output count designation ........................................................ D7
• Output frame No. designation................................................. D8 to D12
• Data transmission result ......................................................... D20
(b) Intelligent function module switch settings (Refer to Section 4.5.2)
Bit
Switch No.
Position Designated value
Description
Setting
value
b0 OFF Operation setting Independent
b1 ON Data bit 8 bits
b2 OFF Parity bit No
b3 OFF Even/odd parity Odd
b4 OFF Stop bit 1 bit
b5 OFF Sum check code No
b6 ON Write during RUN Enabled
b7 ON
Transmission
setting
Setting modifications Enabled
Switch 1
b8 to b15 — Communication rate setting 19200bps
07C2H
Switch 2 — Communication protocol setting Non-procedure protocol 0006H
Switch 5 — Station number setting Station 0 0000H
