App. - 11 App. - 11
MELSEC-Q
PPENDIXES
Appendix 2.2.2 Installing on existing systems
The following explains the Installation of the Q series C24 on an existing system.
(1) Installing on a multidrop connection system
The Q series C24 can be installed on an existing system to which the
programmable controller CPU and external devices are connected as 1:n or m:n
multidrop connection (
1).
1 This is when a QC24(N) or a computer link module (such as AJ71UC24) is
used as the programmable controller CPU module of the multidrop
connection.
However, there are frame restrictions when data communication is performed.
(See the Reference Manual.)
(2) Replacing the QnACPU module with a QCPU
The wiring used by the QC24(N) can be used as is.
POINT
The functional use is the same, except for the functions added by the Q series C24
to the conventional module. However, with the introduction of high-speed QCPUs,
there may be cases in which communication cannot be performed normally when a
programmable controller module in the QnA series is replaced by a Q series
programmable controller. When a module is changed to a Q series programmable
controller module, make sure to perform an operation check.
To Next Page
