3-49
Parallel input/output unit
3 Controller
・The signals assigned as dedicated inputs can be used as general-purpose inputs during program execution. Note
that for safety proposes, these should not be shared with the general-purpose inputs other than for numeric
value inputs. The signals assigned as dedicated outputs cannot be used in the program. An alarm will occur dur
-
ing operation if used.
Fig.3-8 ： Parallel input/output unit (in the control unit) connection and pin layout
Output 0 to 15
＜CN100＞
50
1
25
26
C o n t r o l l e r b a c k s i d e
C o n n e c t o r p i n l a y o u t
Input 0 to 15
*The I/O card in the control unit is equal to the PIO unit of the option.
(Input 32/Output 32 points)
