MODELS: WS-48315 / WS-55315 / WS-65315
Items in the table below are set following Initalization.
4. LED Indicator Diagnostics
The “Power ON LED” provides an indication of the sets operation, and the possible cause of a malfunction.
A. Initial Control Circuitry Check
Immediately after the TV is connected to an AC power source:
• The LED flashes three times ... indicating the Microprocessor has initialized and is functioning
properly.
• If the LED does not flash ... the Microprocessor is NOT functioning.
B. Error Code Operational Check
Note: The TV must be in “Shut Down” and not heve been switched Off, to perform the Error Code Opera-
tional Check. When the TV is switched Off, the code automatically resets to “12” No Error.
Pressing the front panel “INPUT” and “MENU” buttons at the same time, and holding for 5 seconds,
activates the Error Code Mode. The LED flashes denoting a two digit Error Code, or indicating no problem
has occured since the last Initalization.
Note: The front panel buttons must be used, NOT those on the Remote Control.
• The number of flashes indicates the value of the MSD (tens digit) of the Error Code.
• The flashing then pauses for approximately 1/2 second.
• The LED then flashes indicating the value of the LSD (ones digit) of the Error Code.
• The Error Code is repeated a total of 5 times.
Example: If the Error Code is “23”, the LED will flash two times, pause, and then flashes three
times.
C. Error Codes
The Error Code designations indicating a malfunction, or no malfunction, are listed below:
Error Code Description
12 No error has occurred.
21 X-Ray Protect circuit.
22 Short Protect circuit.
23 Deflection failure.
A/V Memory
Ant-A
Ant-B
DTV
NTSC
1/2/3
COMP
1/2
MonLink
TV Contrast
Max Max Max Max Max
TV Brightness
Center Center Center Center Center
TV Sharpness
Center Center Center Center Center
TV Color
Center Center Center Center Center
TV Tint
Center Center Center Center Center
TV Color Temp.
High High High High High
Video Noise
Standard Standard Standard Standard Standard
TV Image Type
Video Video Video Video Video
TV SVM
Sharpness
On On On On On
TV Bass
Center Center Center Center Center
TV Treble
Center Center Center Center Center
TV Balance
Center Center Center Center Center
TV Surrond
Off Off Off Off Off
TV Listen To
Stereo Stereo Stereo Stereo Stereo
TV Level Sound
Off
Off
Off
Off
Off
AV Memory Initial Settings
